| Brand Name: | Anycut |
| Model Number: | ZKSVD370PRO |
| MOQ: | 1 piece |
| Price: | ￥$2398~2826/piece |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 1~4 pieces/3days;5~30pieces/15 days;31~100pieces/20days |
1. Efficient & Stable Feeding
- Suction-type fully automatic paper feeding effectively eliminates static electricity, ensuring smooth and consistent material handling.
2. High-Speed Dual-Head Performance
- Driven by a high-speed servo motor with double heads, enabling a max cutting speed of 1600mm/s for high-volume production.
3. Versatile Cutting Capabilities
- Supports full cut, half cut, and crease cut in one pass, making it ideal for batch processing.
- Can handle a wide range of materials, up to a thickness of 450gsm.
4. Precision & Intelligence
- Features an automatic contour cut camera for precise, automated cutting.
5. Flexible Connectivity
- Offers WIFI wireless connection, along with USB cable, UDisk, and web cable interfaces
6. User-Friendly & Robust Design
- Compatible with CDR, AI, PS, Contour, and Signmaster (optional).
Product Parameters
| MODEL | ZKSVD370PRO |
| Max. media width | 370mm |
| Max. cutting width | 340mm |
| Auto contour cut | Camera (automatically contour cutting) |
| Control panel | 5.0inch touch screen |
| Motor | High speed servo motor |
| Positoning mode | Qr code/Dot/Right angle |
| Number of heads | 2 |
| Blade type | Rowland blade |
| Packing size | Host machine: L 960mm*W 960mm*H 780mm; Cabine: L 910mm*W 890mm*H 860mm |
| Machine size | L 790mm*W 790mm*H 1200mm |
| Gross/Net weight | 206kgs/142kgs |
| Cutting accuracy | +/- 0.01mm |
| Repeatability | 0.082mm |
| Max.material thickness | 450gsm |
| Max. cutting speed | 1600mm/s |
| Max.force | 2000g |
| Connect or interface | USB cable/Udisk/web cable/WIFI |
| Power | ﹤150w |
| Working environment | ﹢5℃-﹢35℃ |
| Power supply | 100v-240v(adaptive) |
| Suitable cutting material | Self-adhesive sticker/coated paper/PVC |
| Support software | CDR/AI/PS/Contour software/Signmaster(optional) |
| Memory | 1G |
| Support system | All versions of windows |
