Anycut A3/A4 Sticker Label Cutting Machine Servo Motor Canning Code CCD Camera

Anycut A3/A4 Sticker Label Cutting Machine Servo Motor Canning Code CCD Camera

Brand Name: Anycut
Model Number: ZKSV350
MOQ: 1 piece
Price: $856-1256/piece
Payment Terms: T/T,Western Union
Supply Ability: 1-4 pieces：2days ;5-30 pieces：2-15 days;30-100 pieces:20 days
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen
Certification:
CE/FCC/RoHS
Auto Contour Cut:
CCD Camera For Automatic Positioning
Control Panel:
4.3inch Touch Screen
Max.material Thickness:
450gsm
Max.cutting Speed:
1500mm/s
Max.force:
2000g
Connect Or Interface:
USB Cable/Udisk/web Cable/WIFI
Support Software:
CDR/AI/PS/Contour Software/Signmaster(optional)
Custom OEM/ODM:
Fully Customizable Label Printer - OEM/ODM Services Available
Packaging Details:
L 780mm*W 580mm*H 520mm
Supply Ability:
1-4 pieces：2days ;5-30 pieces：2-15 days;30-100 pieces:20 days
Highlight:

A3 A4 sticker cutting machine

,

servo motor label cutter

,

CCD camera canning code machine

Product Description

Anycut A3/A4 Sticker Label Cutting Machine Servo Motor  Canning Code CCD Camera



The ZKSV350 servo motor die-cutting machine is a high-performance cutting device developed by Hefei Yike CNC. Powered by a servo motor, it delivers far higher precision and stability than traditional stepper motor models, and its 1500mm/s cutting speed greatly boosts processing efficiency, making it an ideal choice for precision processing of special-shaped cards, self-adhesive labels, cultural and creative peripherals and more.

Equipped with a CCD camera for automatic positioning, it supports QR code, dot and right-angle positioning methods. The ±0.01mm cutting accuracy can accurately restore the details of complex patterns, and the 2000g super pressure can easily cut 450gsm thick materials. In terms of operation, WIFI wireless connection and code-scanning file retrieval simplify the process, and the 4.3-inch LCD touch screen is intuitive and easy to understand, even for beginners to master quickly.

With a compact body of 693×480×295mm, it fits various store scenarios, and is compatible with all Windows systems and multiple design software. Whether for small-batch personalized customization or large-scale production, it can achieve efficient and precise cutting operations by virtue of the advantages of the servo motor.


MODEL ZKSV350
Max. media width 345mm,A4/A3/A3+
Max. cutting width 330mm
Cutting length Unlimited
Auto contour cut Camera (automatically contour cutting)
Control panel 4.3inch touch screen
Motor servo motor
Positoning mode Qr code/Dot/Right angle
Number of heads 1
Blade type Rowland blade
Packing size L 780mm*W 580mm*H 520mm
Machine size L 693mm*W 480mm*H 295mm
Gross/Net weight 52kgs/37kgs
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.material thickness 450gsm
Max. cutting speed 1500mm/s
Max.force 2000g
Connect or interface USB cable/Udisk/web cable/WIFI
Power ﹤150w
Working environment ﹢5℃-﹢35℃
Power supply 100v-240v(adaptive)
Support software CDR/AI/PS/Contour software/Signmaster(optional)
Memory 1G
Support system All versions of windows
