Anycut Double-Head Graph Plotter Adsorption Batch Production Cutting Machine with Servo Motor

Anycut Double-Head Graph Plotter Adsorption Batch Production Cutting Machine with Servo Motor

Brand Name: Anycut
Model Number: SVD370PRO_RL
MOQ: 1 piece
Price: $2826-3682/piece
Payment Terms: T/T,Western Union
Supply Ability: 1-4 pieces：2days ;5-30 pieces：2-15 days;30-100 pieces:20 days
Detail Information
Product Description
Detail Information
Place of Origin:
Shenzhen
Certification:
CE/FCC/RoHS
Cutting Machine:
Adsorption Batch Production Cutting
Servo Motor:
High Speed Servo Motor
Auto Contour Cut:
Automatically Camera Contour Cutting
Control Panel:
4.3inch Touch Screen
Suitable Cutting Material:
Self-adhesive Sticker/coated Paper/PVC
Support Software:
CDR/AI/PS/Contour Software/Signmaster(optional)
Half Cut:
Full Cut And Half Cut/crease And Cut At One Time
Dual Knife Heaed Carriage:
Effectively Eliminate Static Electricity And Avoid Double-sheet Feeding
Packaging Details:
L 890mm*W 580mm*H 570mm
Supply Ability:
1-4 pieces：2days ;5-30 pieces：2-15 days;30-100 pieces:20 days
Highlight:

double-head graph plotter cutting machine

,

adsorption batch production plotter

,

servo motor graph plotter machine

Product Description

Anycut Double-Head Graph Plotter Adsorption Batch Production Cutting Machine with  Servo Motor



The SVD370PRO_RL is an intelligent die-cutting machine focusing on efficient batch processing, with adsorption wheel indentation and suction feeding technology as its core highlights. It can effectively eliminate static electricity and avoid double-sheet feeding, and hold up to 1000 sheets at a time, greatly improving the processing efficiency of self-adhesive stickers, special paper, personalized business cards and other materials. The 370mm media width is suitable for processing small and medium-sized materials; 3000g pressure can cut 600gsm thick materials, and a 1600mm/s cutting speed makes large-batch operations more efficient.

Equipped with a 5.0-inch LCD touch screen, it supports WIFI, USB and network cable connections—one machine can link multiple computers, and USB flash drive offline operation is also easy to achieve. The dual Roland cutter heads plus CCD camera for fully automatic positioning, with ±0.01mm cutting accuracy, can precisely cut special-shaped cards and cartons, and full cutting, half cutting and indentation can be completed in one go. The high-speed servo motor ensures stable operation, and the dual-head carriage structure adapts to diverse processing needs, making it a practical cutting device for graphic shops and small processing plants.


MODEL SVD370PRO_RL
Max.media width 370mm
Max.media width 370mm
Auto contour cut Camera(automatically contour cutting)
Controlpanel 4.3inch touch screen
Motor High speed servo motor
Positioning mode Qr code/Dot/right angle
Number of heads 2
Blade type Rowland blade
Packing size L 890mm*W 580mm*H 570mm
Machine size L 770mm*W 480mm*H 370mm
Gross Net weight 63kgs/47kgs
Cutting accuracy +/- 0.01mm
Repeatability 0.082mm
Max.media thickness 450gsm
Max.cutting speed 1600mm/s
Max.force 3000g
Connect interface USB/Lan/Wifi/web cable/MFI
Power <150W
Working environment ﹢5℃-﹢35℃
Power supply 100~240V (adaptive)
Suitable cutting material Self-adhesive sticker/coated paper/PVC
Support software CDR/AI/PS/Contour software/Signmaster(optional)
Memory 1G
Support system All versions of windows



Anycut Double-Head Graph Plotter Adsorption Batch Production Cutting Machine with Servo Motor 0
