| Brand Name: | Anycut |
| Model Number: | ZKD1000 |
| MOQ: | 1Piece |
| Price: | $613~827/piece |
| Payment Terms: | T/T,Western Union |
| Supply Ability: | 1~4 pieces/2 days;5~30 pieces/15 days;31~100 pieces/20 days |
ZKD1000 700mm/s Double Head Professional Crystal Label Cutting Plotter With CCD Contour Positioning
The ZKD1000 is a versatile dual-head cutting plotter engineered to deliver precision and efficiency for high-volume sticker, label, and graphic production.
- Dual-Head Design & 2000g Cutting Force:
With two Roland blades and a powerful 2000g max cutting force, it handles full-cut, half-cut, and crease-and-cut operations in a single pass.
- Camera Auto-Positioning:
The built-in camera automatically locates pre-printed registration marks, ensuring accurate contour cutting even with large-format materials, and delivers a precision of ±0.01mm for consistent, professional results.
- Flexible Connectivity:
Supports USB, U-disk, and optional Wi-Fi for seamless data transfer, allowing you to easily integrate it into your existing workflow.
- User-Friendly Operation:
The 5.0-inch LCD touchscreen provides intuitive control.
- Broad Compatibility:
Works with CDR, AI, PS, Contour, and Signmaster software, and supports all Windows operating systems for maximum flexibility.
| MODEL | ZKD1000 |
| Max. media width | 1000mm |
| Max. cutting width | 850mm |
| Packing size | L1360mm*W400mm*H440mm |
| Machine size | L1250mm*W600mm*H1100mm |
| Gross/Net weight | 36kgs/30kgs |
| Control panel | 5.0inch LCD touch screen |
| Motor | Stepper |
| Cutting length | Unlimited |
| Cutting accuracy | +/- 0.01mm |
| Repeatability | 0.082mm |
| Max.cutting speed | 700mm/s |
| Max.force | 2000g |
| Main board | ARM smart dual-core chip |
| Auto contour cut | Camera |
| Number of heads | 2 |
| Blade type | Rowland blade |
| Floorstand | yes |
| Drawing instruction | Automatic recognition DMPI and HPGL |
| Connect or interface | USB cable/Udisk/WIFI(optional) |
| Power | ﹤100w |
| Working environment | ﹢5℃﹣﹢35℃ |
| Power supply | 100v-240v(adaptive),50HZ/60HZ |
| Support software | CDR/AI/PS/Contour software/signmaster(optional) |
| Memory | 1G |
| Support system | All versions of windows |
